Origins

Sherlock Scenario

A major incident has recently occurred at Forela. Approximately 20 GB of data were stolen from internal s3 buckets and the attackers are now extorting Forela. During the root cause analysis, an FTP server was suspected to be the source of the attack. It was found that this server was also compromised and some data was stolen, leading to further compromises throughout the environment. You are provided with a minimal PCAP file. Your goal is to find evidence of brute force and data exfiltration.

Sherlock	Origins
Category	DFIR
Difficulty	Very Easy
Creator	CyberJunkie
Released	20th March, 2025

Resources

FTP is one of the oldest file transfer protocols still running in production environments today, and from a security standpoint it’s a goldmine.

• No encryption by default.
• Credentials in cleartext.
• Every command and response visible in plain text on the wire.
• An attacker’s entire session, what they downloaded, what they tried to upload, what they were looking for.

I’ve created a comprehensive cheatsheet which serves as a practical reference for anyone analyzing FTP traffic in Wireshark, whether you’re working through a CTF challenge, investigating a suspected breach, or just trying to build your blue team fundamentals. It covers the commands you’ll encounter on the wire and what they actually mean, the response codes that tell you whether an operation succeeded or failed and a ready-to-use set of Wireshark display filters.

The session we’re working through in this post is a real-world example involving a brute-force attack, post-authentication reconnaissance, and sensitive file exfiltration. By the end, you’ll be able to open a pcap and read an FTP session.

Let’s get into it. 😎

FTP Commands Cheatsheet

Auth & session

Command	Direction	What it does
USER	Client→Server	Sends the username to log in
PASS	Client→Server	Sends the password — cleartext in plain FTP
QUIT	Client→Server	Graceful disconnect; server responds 221
SYST	Client→Server	Asks the server OS type — leaks server info (e.g. UNIX Type: L8)
FEAT	Client→Server	Lists supported extensions — fingerprints server capabilities
AUTH TLS	Client→Server	Upgrades connection to TLS (FTPS). Absence = plaintext session

Data channel setup

Command	Direction	What it does
PORT	Client→Server	Active mode — client tells server which IP:port to connect back to
PASV	Client→Server	Passive mode — client asks server for an IP:port to connect to
EPSV	Client→Server	Extended passive mode (IPv4/IPv6) — response is 229 (\|PORT\|)
EPRT	Client→Server	Extended active mode — carries IP version, IP, and port explicitly

File & directory operations

Command	Direction	What it does
LIST	Client→Server	Long directory listing (like ls -l). Sent over data channel
NLST	Client→Server	Name-only listing — just filenames, no metadata
RETR	Client→Server	Download a file from the server
STOR	Client→Server	Upload a file to the server — watch for exfil or backdoor drops
STOU	Client→Server	Upload with unique auto-generated filename
APPE	Client→Server	Append data to an existing file
DELE	Client→Server	Delete a file on the server
REN	Client→Server	Rename file — uses RNFR (from) then RNTO (to)
MKD	Client→Server	Create directory
RMD	Client→Server	Remove directory
CWD	Client→Server	Change working directory
PWD	Client→Server	Print working directory — reveals remote file path structure
CDUP	Client→Server	Move up one directory level

Transfer control

Command	Direction	What it does
TYPE	Client→Server	Set transfer type:  TYPE A = ASCII & TYPE I = Binary
SIZE	Client→Server	Get file size in bytes before downloading — useful to track exfil volume
MDTM	Client→Server	Get file last-modified timestamp in YYYYMMDDhhmmss format
REST	Client→Server	Resume transfer from a byte offset — indicates partial/chunked downloads
ABOR	Client→Server	Abort current transfer
NOOP	Client→Server	Keep-alive — server responds 200. Used to keep idle sessions alive
SITE	Client→Server	Server-specific commands (e.g. SITE CHMOD) — high-value in IR

FTP Response Codes

1xx — Positive preliminary

Code	Meaning	Context
150	File status OK, opening data connection	Seen before LIST, RETR, STOR transfers

2xx — Positive completion

Code	Meaning	Context
200	Command OK	Generic success (e.g. after TYPE I)
211	System status / feature list	Response to FEAT — lists supported extensions
213	File status	Used by SIZE and MDTM to return size/timestamp
215	OS name	Response to SYST — e.g. UNIX Type: L8
220	Service ready / banner	First packet from server — may reveal software and version
221	Service closing	Goodbye after QUIT
226	Transfer complete	Data transfer finished successfully
227	Entering passive mode	Contains IP:port in (h1,h2,h3,h4,p1,p2) format — extract port
229	Entering extended passive mode	Contains (\|PORT\|) — port only, used with EPSV
230	Login successful	User authenticated
250	Requested action OK	After CWD, DELE, RMD, etc.
257	Path created / current directory	After MKD or PWD — reveals server path structure

3xx — Positive intermediate

Code	Meaning	Context
331	Username OK, need password	After USER — normal auth flow
350	Pending further info	After RNFR — waiting for RNTO to complete rename

4xx — Transient negative (retriable)

Code	Meaning	Context
421	Service unavailable	Server closing connection — timeout or shutdown
425	Can’t open data connection	Firewall/NAT issue with passive/active mode
426	Connection closed, transfer aborted	Interrupted mid-transfer
430	Invalid username or password	Seen in brute-force attempts (RFC 2228)

5xx — Permanent negative

Code	Meaning	Context
500	Syntax error, unrecognized command	Typo or unsupported command sent
501	Syntax error in arguments	Bad parameters for a valid command
502	Command not implemented	Server doesn’t support the requested command
530	Not logged in	Auth failed — key indicator in brute-force detection
550	No such file / permission denied	Access control — watch for repeated 550 on STOR (write attempts)
553	File name not allowed	Filename rejected by server policy

Wireshark Filters

Authentication events

# Successful logins
ftp.response.code == 230

# Failed logins (not logged in / auth failure)
ftp.response.code == 530

# Any login failure codes (530 or 430)
ftp.response.code == 530 || ftp.response.code == 430

# Capture credentials (USER and PASS commands)
ftp.request.command == "USER" || ftp.request.command == "PASS"

File transfer activity

# All downloads
ftp.request.command == "RETR"

# All uploads (potential exfil or web shell drops)
ftp.request.command == "STOR" || ftp.request.command == "STOU" || ftp.request.command == "APPE"

# File size lookups before transfer
ftp.request.command == "SIZE"

# File deletion
ftp.request.command == "DELE"

# Directory listing (reconnaissance)
ftp.request.command == "LIST" || ftp.request.command == "NLST"

Server fingerprinting

# Banner capture (first server packet)
ftp.response.code == 220

# OS fingerprinting via SYST
ftp.request.command == "SYST"

# Feature enumeration via FEAT
ftp.request.command == "FEAT"

Data channel & session

# Passive mode negotiations (find ephemeral data ports)
ftp.response.code == 227 || ftp.response.code == 229

# All FTP control channel traffic (port 21)
ftp

# FTP data channel traffic (follow the data stream)
ftp-data

# Complete session for a specific IP
ip.addr == <target_ip> && (ftp || ftp-data)

Permission denials & errors

# Permission denied responses
ftp.response.code == 550

# All 5xx errors (permanent failures)
ftp.response.code >= 500 && ftp.response.code < 600

Directory traversal suspicion

# CWD commands (watch for ../ sequences in argument)
ftp.request.command == "CWD"

# Path disclosure via PWD
ftp.request.command == "PWD" || ftp.response.code == 257

Solution

Question 1

What is the attacker’s IP address?

The Endpoints view (IPv4 tab) gives you a bird’s-eye summary of who is talking to whom and how much data moved. Most entries have about 2 packets and 112 bytes which is more of background noise. Two entries highlighted however have a high packet count:

Thought Process:

172.31.45.144 (The Internal Server)

The 172.31.0.0/12 range is an RFC 1918 private address space, meaning this IP is sitting inside a local/internal network such as a home lab, a corporate LAN, a cloud VPC private subnet (AWS, for instance, assigns 172.31.x.x to EC2 instances inside a default VPC). This is the FTP server being attacked. It has the higher packet count because it’s responding to every single one of the attacker’s requests including all those 530 rejection messages.

15.206.185.207 (The External Attacker)

15.206.x.x is an ARIN-allocated public IP block belonging to Amazon Web Services, but crucially it is a public-facing address, not a private one. This is the machine on the other end of the internet making inbound connections to the internal server. The 62 kB and 444 packets it generated represent the flood of brute-force authentication attempts. The fact that it’s also an AWS IP is worth noting as attackers frequently spin up cloud VMs to conduct attacks because they’re cheap, disposable, and harder to attribute.

Switching to the TCP tab breaks conversations down by port, and one row is unique:

Port 21 is the FTP control channel . This is where all the commands and responses travel (USER, PASS, 230, 530, etc.). The fact that 172.31.45.144:21 has 398 packets , nearly the entire IPv4 conversation volume tells you almost all traffic in this capture is FTP control plane chatter. That’s consistent with a brute-force scenario. Thousands of USER/PASS attempts generate enormous numbers of small control packets while producing almost no data channel activity.

Applying the ftp.response.code == 530 filter , you get Login incorrect responses, all flowing from 172.31.45.144 to 15.206.185.207. In FTP, a 530 is the server telling the client “Wrong credentials” . So the server (172.31.45.144) is rejecting repeated login attempts coming from 15.206.185.207. That pattern (dozens of 530s in a matter of seconds across a two-to-three minute window), is a clear indicator of a FTP brute-force attack.

15.206.185.207

Question 2

It’s critical to get more knowledge about the attackers, even if it’s low fidelity. Using the geolocation data of the IP address used by the attackers, what city do they belong to?

https://ipinfo.io/15.206.185.207?lookup_source=search-bar

Mumbai

Question 3

Which FTP application was used by the backup server? Enter the full name and version. (Format: Name Version)

ftp.response.code == 220

Code	Meaning	Context
220	Service ready / banner	First packet from server (may reveal software and version)

vsFTPd 3.0.5

Question 4

The attacker has started a brute force attack on the server. When did this attack start?

(ip.src == 15.206.185.207) && (ftp.request.command == "USER")

2024-05-03 04:12:54

Question 5

What are the correct credentials that gave the attacker access? (Format username:password)

# Success
ftp.response.code == 230

# Login incorrect
ftp.response.code == 530

Filter for Successful Logins and Follow TCP Stream as shown:

You will notice the username & password used to successfully log into the FTP server.

forela-ftp:ftprocks69$

Question 6

The attacker has exfiltrated files from the server. What is the FTP command used to download the remote files?

Apply the following filter to show potential exfiltration attempts:

ftp.request.command == "RETR"

Note:

Command	Direction	What it does
RETR	Client→Server	Download a file from the server

To download the files, click on File > Export Objects > FTP-DATA

Save All

Command Used: RETR

Question 7

Attackers were able to compromise the credentials of a backup SSH server. What is the password for this SSH server?

Inspecting the PDF extracted reveals the SSH temporary password mentioned in the Contingency Plan

**B@ckup2024!**

Question 8

What is the s3 bucket URL for the data archive from 2023?

Inspecting the s3_buckets.txt file reveals the s3 bucket URL containing bulk data from 2023

https://2023-coldstorage.s3.amazonaws.com

Question 9

The scope of the incident is huge as Forela’s s3 buckets were also compromised and several GB of data were stolen and leaked. It was also discovered that the attackers used social engineering to gain access to sensitive data and extort it. What is the internal email address used by the attacker in the phishing email to gain access to sensitive data stored on s3 buckets?

Inspecting the s3_buckets.txt file reveals an internal email address likely used by the attacker in the phishing email.

`archivebackups@forela.co.uk
